Large Aperture Electric Rectangular Vacuum Gate Valve for Space Simulation and Coating Systems

This high-performance Large Diameter Electric Rectangular Valve is a heavy-duty vacuum isolation and transmission equipment specifically designed for ultra-high vacuum, extra-large openings, and space simulation or large-scale coating system conditions. Featuring a large-sized rectangular straight-through structure, it is suitable for the full range from ultra-high vacuum to atmospheric pressure (5×10⁻⁸ Pa to 1×10⁵ Pa). It enables rapid isolation and sealed cutoff for large process chambers and vacuum systems. With advantages such as consistent valve plate sealing pressure, integrated control, stable dynamic balance, and high customizability, it is the standard core valve for large-scale vacuum system isolation.

Core Features

• Extra-Large Rectangular Port Design: Perfectly adapts to various non-standard large-sized chambers, meeting the requirements for high flow rates and high throughput. Dimensions can be fully customized according to customer needs.
• Flexible Dual-Drive Adaptation: Supports Electric + Pneumatic dual-drive modes with integrated control. This ensures convenient operation, easy maintenance, and seamless adaptation to automated production lines.
• Dual Installation Structures: Available in both Suspended and Guide Rail installation types to suit different structural layouts and installation requirements of large-scale vacuum systems.
• Premium Materials & High-End Customization: The main body is constructed from high-quality Stainless Steel (optional materials available), offering high strength, corrosion resistance, and low outgassing, making it ideal for ultra-clean and harsh environments.
• Dual Sealing Options: Choose between Rubber O-ring sealing or Bellows shaft sealing based on process requirements to meet different vacuum levels and sealing standards.
• Expandable Temperature Control: Supports optional Water Cooling Modules and Temperature Control Modules to effectively manage valve temperature, adapting to high-temperature processes and extending equipment lifespan.

Product Specifications

Application Fields

Our high-performance vacuum valves are widely utilized in the following demanding sectors:

• Space Simulation Systems: Ideal for isolating giant vacuum chambers in space environment simulation capsules and large-scale vacuum testing devices.
• Large-Scale Coating Systems: Used for vacuum line switching and chamber isolation in large-scale coating production lines, such as optical coating and roll-to-roll coating.
• Giant Vacuum Apparatus: Provides isolation and control for ultra-large volume systems in scientific research facilities, vacuum furnaces, and massive industrial chambers.
• Customized Vacuum Systems: Supports customized vacuum solutions for non-standard large rectangular chambers and special process requirements.

Frequently Asked Questions (FAQ)

Product Summary

The Large Diameter Electric Rectangular Valve integrates ultra-large rectangular adaptation, dual-drive integrated control, stable dynamic balance, and customizable temperature management. It stands as a benchmark for high-end large-scale vacuum system isolation. By relying on its superior sealing performance and robust stainless steel construction, it meets the most rigorous demands of space simulation and industrial coating. Whether for standard giant chambers or non-standard customized systems, this valve provides a safe, stable, and durable solution for the most challenging vacuum environments.
