This comprehensive guide covers KF vacuum clamp specifications (including detailed size charts for KF16-KF50), material selection, installation best practices, and answers to 10 critical FAQs about vacuum system connections.

Product Introduction: KF Vacuum Clamps

KF vacuum clamps provide fast, reliable connections for vacuum pipelines, offering superior leak-tight performance from rough to high vacuum applications.

Key Features

✔ Multiple sizes - KF16 (KF10) to KF50 available
✔ Material options - Lightweight aluminum or durable stainless steel
✔ Precise dimensions - Standardized ISO-KF specifications
✔ Universal compatibility - Works with all KF series components
✔ Quick assembly - Saves installation time vs. bolted flanges

Technical Specifications & Size Chart

Additional Specifications:

Materials: 6061 Aluminum or 304/316 Stainless Steel

Temperature Range: -20°C to 150°C (Aluminum), -20°C to 300°C (Stainless)

Pressure Rating: Full vacuum to 4 bar (dependent on material)

Surface Finish: Anodized (Aluminum), Electropolished (Stainless)

Industry Application Cases

Case 1: Semiconductor Vacuum Cluster Tool

Used KF40 stainless clamps to achieve:

10⁻⁹ mbar leak-tight connections

Withstood daily 200°C bakeouts

Zero particulate generation

Case 2: Research Laboratory System

Performance highlights:

Quick reconfiguration using KF25 clamps

Aluminum clamps reduced system weight by 35%

5+ years of maintenance-free operation

Case 3: Industrial Coating Equipment

Key results:

KF50 clamps handled 10⁵ pump-down cycles

No seal degradation observed

30% faster maintenance turnaround

KF Vacuum Clamp FAQs

1. How do I select the right KF clamp size?

Match to your flange size - KF16 for 16mm, KF25 for 25mm, etc. See our size chart above.

2. What's the proper installation torque?

Hand-tighten plus 1/4 turn with wrench. Typical torque:

KF16: 1.5-2 Nm

KF25: 2-2.5 Nm

KF40: 2.5-3 Nm

KF50: 3-4 Nm

3. When should I choose stainless steel over aluminum?

Stainless steel is preferred for:

High temperature (>150°C)

Corrosive environments

Frequent bakeout cycles

Ultra-high vacuum systems

4. How often should clamps be inspected?

Annually for general use, every 6 months for critical applications.

5. Can I reuse KF clamps?

Yes, but always replace O-rings and inspect for:

Cracks or deformation

Thread damage

Surface corrosion

6. What O-ring materials are compatible?

Common options include:

Viton® (standard)

EPDM (for high temperature)

Silicone (for food/pharma)

Kalrez® (for aggressive chemicals)

7. How to prevent vacuum leaks?

Clean flange surfaces before assembly

Lubricate O-rings lightly

Tighten clamps evenly in star pattern

Perform helium leak check for UHV

8. What's the maximum pressure rating?

Aluminum: 2 bar

Stainless: 4 bar
(At room temperature, decreases with temperature)

9. Can KF clamps be used with corrosive gases?

Yes, with:

316L stainless steel clamps

Chemically resistant O-rings

Proper surface finish (electropolished)

10. Where can I get replacement parts?

Purchase from original manufacturers for guaranteed:

Dimensional accuracy

Material certification

Vacuum performance

Conclusion

KF vacuum clamps provide reliable, standardized connections for vacuum systems across industries. Understanding the size specifications (KF16 to KF50) and material options ensures optimal performance for your specific application.

For critical vacuum systems, always:
✓ Select the appropriate clamp material
✓ Follow proper installation procedures
✓ Perform regular maintenance checks

Contact our vacuum specialists for assistance in selecting the perfect KF clamps for your system requirements and operating conditions.
