Vacuum gauge CMR series capacitive film sales and repair
Capacitive film vacuum gauge CMR series Product advantages:
1. No memory influence: the measurement accuracy is not affected by the composition of the measured object;
2. No wear, pollution resistance, full range of anti-corrosion;
3. Use materials with consistent coefficient of thermal expansion: excellent temperature compensation ability;
4. Excellent 0-point stability, air shock resistance, no additional protection valve
|
Capacitive film vacuum gauge CMR series technical parameters:
|
Model
|
CMR 361
|
CMR 362
|
CMR 363
|
CMR 364
|
CMR 365
|
|
interface
|
Pipe OD ½"
DN 16 ISO-KF
DN 16 CF-R
Cajon 8 VCR
|
Pipe OD ½"
DN 16 ISO-KF
DN 16 CF-R
|
Pipe OD ½"
DN 16 ISO-KF
DN 16 CF-R
Cajon 8 VCR
|
Pipe OD ½"
DN 16 ISO-KF
DN 16 CF-R
Cajon 8 VCR
|
Pipe OD ½"
DN 16 ISO-KF
DN 16 CF-R
Cajon 8 VCR
|
|
Output signal V
|
1.0-9.8
|
1.0-9.8
|
1.0-9.8
|
1.0-9.8
|
1.0-9.8
|
|
Signal transmission distance m
|
120
|
120
|
120
|
120
|
120
|
|
Baking temperature °C
|
110
|
110
|
110
|
110
|
110
|
|
Operating ambient temperature °C
|
+5-+55
|
+5-+55
|
+5-+55
|
+5-+55
|
+5-+55
|
|
Storage ambient temperature °C
|
-40-+65
|
-40-+65
|
-40-+65
|
-40-+65
|
-40-+65
|
|
Withstand maximum pressure
|
3 bar
|
2 bar
|
2 bar
|
2 bar
|
1.3 bar
|
|
precision
|
0．2% of reading
|
0．2% of reading
|
0．2% of reading
|
0．2% of reading
|
0．2% of reading
|
|
0 point drift
|
0.005%F.S./ ℃
|
0.005%F.S./ ℃
|
0.005%F.S./ ℃
|
0.015%F.S./ ℃
|
0.02%F.S./ ℃
|
|
Maximum range
|
1100 mbar
|
110 mbar
|
11 mbar
|
1.1 mbar
|
0.11 mbar
|
|
Minimum range
|
0.1 mbar
|
1E-2 mbar
|
1E-3 mbar
|
1E-4 mbar
|
1E-5 mbar
|
|
Supply voltage VDC
|
14-30
|
14-30
|
14-30
|
14-30
|
14-30
|
|
Power consumption W
|
1
|
1
|
1
|
1
|
1
|
|
Probe material
|
Ceramic + stainless steel
|
Ceramic + stainless steel
|
Ceramic + stainless steel
|
Ceramic + stainless steel
|
Ceramic + stainless steel
|
|
Capacitive film vacuum gauge CMR series size and pumping speed:
