Two-stage vacuum pump
TX-08D double stage vane vacuum pumps
TX-08D double stage vane vacuum pumps
TX-08D double stage vane vacuum pumps
TX-08D double stage vane vacuum pumps

TX-08D double stage vane vacuum pumps

These pumps are suitable for pumping air and other gases. It can be used alone, can also be used for booster pumps, diffusion pumps, molecular pumps, maintenance pumps, titanium pump vacuum pumps, widely used in vacuum metallurgy, vacuum coating, vacuum drying, freeze drying, vacuum degassing, vacuum packaging, vacuum, vacuum forming, food packaging, printing, sputtering, vacuum casting, photovoltaic, science and technology, chemical industry, electronics, refrigerators, air conditioning pipelines and laboratory vacuum operation and supporting use
  • Item NO :

    TX-08D
  • Motor power :

    500W
  • Pumping speed :

    8m³/h/9.6m³/h
  • Limit vacuum :

    3×10-3 mbar

TX-08D double stage vane vacuum pumps

 Specification parameters

Technical parameter

Unit

Frequency

TX-08D

Pumping speed

m3/h

50 Hz

8

Limit partial pressure

mbar

50 Hz

4×10-4

Limit total pressure

mbar

50 Hz

3×10-3

Open limit total pressure

mbar

50 Hz

6×10-3

Water vapor permitted tolerance

mbar

50 Hz

30

Nomimal size

DNmm

50 Hz

KF25

Noise

(ENISO2151)

dB(A)

54/56

Oil filling level(Max./min.)

L



1.0/0.7

Weight(not filled )

kg



27

Operating temperature(lowest/highest)



5/40

Power

W

50 Hz

550/550Single phase 220V/Double phase 380V

Total height of pump

mm



272

Total length of pump

mm



500
