KC Series High Vacuum Oil Diffusion Pump - Reliable High Vacuum Solution for Industrial Applications

KC Series High Vacuum Oil Diffusion Pump—The Ideal Choice for High-Performance Vacuum Acquisition Equipment

The KC series high vacuum oil diffusion pump is an ideal device for fields such as vacuum heat treatment, brazing, and vacuum coating, featuring a wide working range, high critical foreline pressure, and low backstreaming rate. Learn about its technical parameters, product advantages, and FAQs to choose a high-quality high vacuum solution.

Target Industry or Application Scenario Description

The KC series high vacuum oil diffusion pump is designed for industrial applications requiring ultra-high vacuum levels, such as vacuum heat treatment, brazing, and thin-film coating. Its wide operating range, low oil backstreaming rate, and fast startup make it a reliable choice for achieving and maintaining high vacuum levels in demanding environments.

Long-Term Operating Features:

Engineered for durability, the KC series high vacuum oil diffusion pump delivers consistent performance over extended periods.

Its robust construction ensures resistance to wear and tear, making it a reliable choice for long-term industrial use.

The low oil backstreaming rate and efficient cooling system minimize maintenance requirements and operational downtime.

Optimized Highlights:

Ultra-High Vacuum Performance: Achieves and maintains vacuum levels as low as 1.3×10⁻⁵ Pa.

Low Oil Backstreaming Rate: Ensures clean operation with minimal contamination.

Fast Startup: Reduces waiting time and improves operational efficiency.

Durable Design: Built with high-quality materials for long-term reliability.

Versatile Application: Ideal for vacuum heat treatment, brazing, and thin-film coating processes.

Application Case

Application Field: Vacuum Coating

Equipment Used: KC-800 High Vacuum Oil Diffusion Pump

Process Flow: In the optical coating process, the KC-800 provides a stable high vacuum environment, ensuring coating uniformity and quality.

Equipment Installation

Detailed instructions on how to properly install the KC series high vacuum oil diffusion pump, including selecting the installation location, connecting pipelines, and debugging steps to ensure stable and efficient operation. Professional installation guidance from manufacturers is recommended.

Frequently Asked Questions (FAQs) about KC Series High Vacuum Oil Diffusion Pump

What is the ultimate pressure of the KC series high vacuum oil diffusion pump?
Answer: The ultimate pressure is ≤5×10⁻⁵Pa, suitable for high vacuum environments.

What is the backstreaming rate of the KC series high vacuum oil diffusion pump?
Answer: The backstreaming rate is ≤1.5×10⁻³mg/cm²·min, effectively reducing contamination.

How to choose the right model of the KC series high vacuum oil diffusion pump?
Answer: Select the appropriate model based on pumping speed, ultimate pressure, and working environment requirements. Consult professional manufacturers for guidance.

What are the key points for daily maintenance of the KC series high vacuum oil diffusion pump?
Answer: Regularly check the oil level, clean the pump body, and ensure the cooling water system operates normally.

Is the KC series high vacuum oil diffusion pump compatible with other brands of foreline pumps?
Answer: Compatibility depends on the interface size and specifications. Consult the manufacturer for confirmation.

How does the KC series high vacuum oil diffusion pump perform in high vacuum applications?
Answer: It performs excellently in high vacuum environments, with high pumping speed and stable performance.

How to address noise issues in the KC series high vacuum oil diffusion pump?
Answer: Check if the pump oil is sufficient, ensure the cooling water system is normal, and lubricate or replace parts if necessary.

What is the energy efficiency ratio of the KC series high vacuum oil diffusion pump?
Answer: With its efficient heating system, it offers a high energy efficiency ratio and low operating costs.

How durable is the KC series high vacuum oil diffusion pump?
Answer: Made from high-quality materials and precision manufacturing processes, it has a long service life and is suitable for high-intensity working environments.

How to evaluate the total cost of ownership of the KC series high vacuum oil diffusion pump?
Answer: Consider the equipment price, maintenance costs, energy consumption, and pump oil replacement frequency for evaluation. Choose products from reliable manufacturers for cost-effectiveness.

Through this article, readers can gain a comprehensive understanding of the performance, applications, and maintenance of the KC series high vacuum oil diffusion pump, providing professional guidance for selection and usage, while recommending high-quality manufacturers to ensure product quality and service support.
