TXL840D Helium Leak Detector With 15 m3/h Internal Wet Oil-Sealed Rotary Vane Pump

Product Introduction

TXL840D Helium Leak Detector With 15 m3/h Internal Wet Oil-Sealed Rotary Vane Pump

Technical parameters

Minimum leak rate ： detectable   ： Vacuum model  5×10-13Pa·m 3 /s  Absorb gun model： 5×10-9 Pa·m 3 /s

The startup time：≤3min

The response time：≤1.0s

Maximum pressure of leak detection：1500Pa

Before the pumping speed：15m 3 /h

Ion source：Iridium filament coated with yttrium oxide

Ultimate vacuum ： 5×10-4 Pa

Optional leakage rate unit： Pa·m 3  /s, Atm*cc/s, Mbar*l/s , PPM

The power：220V，50Hz，10A 或 110V

The work environment： 5-35℃

Relative humidity： ≤80%

Optional language： Chinese and English

Import flange DN25 ISO-KF

Main configuration
